Description
The machine is driven by a servo motor which is commanded by a PLC program
Machine adjustment is done automatically by HMI (Touchscreen) which is simple
Size adjustment is done automatically by just putting the size of the box on the HMI. Also changing size/job take 5-10 mins as compared to traditional box forming machine which takes around 1 hr.
Machine uses all high quality and branded electricals
The machine has fault alarm function which is automatically displays any issues on the HMI screen
The machine has an emergency stop switch which can automatically stops the machine in case of emergency
The mould can be replaced easily as per different sizes of the box
Technical parameters
| Model | XY-450S |
|---|---|
| Box Size max. | 480*450mm |
| Box Size min | 50*50mm |
| Height | 15-120mm |
| Air supply | 0.6-0.8Mpa |
| Speed | 15-18Pcs/min |
| Total Power | 4kw/220v |
| Machine Dimension | L-1400mm* W-1100mm* H-2300mm |
| Machine weight | 1300 kg |
